Course: Model-Based Systems Engineering with OMG Systems Modeling Language® (v2) and Cameo Systems Modeler (CATIA Magic™) for SysMLv2

Keywords

Keywords

The world's most comprehensive hands-on Systems Modeling Language v2 (SysML®) course presented by one of the world's top SysML® modelling experts.

Designed from the ground up to take attendees through all concepts and notations in a clear sequence, and with examples of the SysMLv2 textual representation modelling code throughout.

Context and structural model for the RadioNet, NetSession, and RadioStation

[TRAIL] SysMLv1: The Webel Radio Net port-based messaging example model in Cameo Systems Modeler and Cameo Simulation Toolkit

Slides in this section

If you want to navigate the entire section including the additional explanatory text click on the title link of the first slide to view the full slide page, then use the next links to move through the slide pages. If you just want to view the slide images only in sequence, click on any slide to view it larger in a viewer, then click again to move through each slide in this tutorial trail section.
Webel Radio Net: The 'RadioNetContext' system context as both an IBD and a BDD
Webel Radio Net: 'structure' SysML Package Diagram
Webel Radio Net: 'channel' SysML Package Diagram
Webel Radio Net: 'net' SysML Package Diagram with the 'RadioNet' system
Webel Radio Net: Focus BDD for block 'NetSession'
Webel Radio Net: 'NetSession' Activities overview
Webel Radio Net: Focus BDD for block 'SessionLog'

Webel Radio Net: Model overview, exchange items, and Ports

[TRAIL] SysMLv1: The Webel Radio Net port-based messaging example model in Cameo Systems Modeler and Cameo Simulation Toolkit

Slides in this section

If you want to navigate the entire section including the additional explanatory text click on the title link of the first slide to view the full slide page, then use the next links to move through the slide pages. If you just want to view the slide images only in sequence, click on any slide to view it larger in a viewer, then click again to move through each slide in this tutorial trail section.
Webel Radio Net: Conventions, terminology, acronyms
Webel Radio Net: SysML Package Diagram as index
Webel Radio Net: Content Diagram as index of table and matrix diagrams
Webel Radio Net: 'value' SysML Package Diagram with custom ValueTypes and Units
Webel Radio Net: 'exchange' SysML Package Diagram with Signals (and Port types)
Webel Radio Net: 'scheduling' SysML Package Diagram with scheduling message Signal families (and Port types)
Webel Radio Net: Focus BDD of the 'InitSession' scheduling Signal and its special role in a net session
Webel Radio Net: 'message' SysML Package Diagram with Message block "packet" and '$msg' String
Webel Radio Net: 'radio' SysML Package Diagram with high level view of Port types for 'Radio' Signals
Webel Radio Net: The RadioMessage Signals
Webel Radio Net: Focus BDD for the SessionSpec exchange item (and the NetManager)

[EXTERNAL LINKS] Cameo Simulation Toolkit (aka Magic Model Analyst) videos and guides

Keywords

Keywords

A collection of EXTERNAL links (scroll down) to videos, slides, and other guides on Magic Model Analyst® (Cameo Simulation Toolkit®). These links are included here as additional resources and do not replace the Webel IT Australia online SysML/MBSE educational resources or the Webel training course materials:

Dr Darren offers some encouragement for those learning Systems Modeling Language (SysML) for Model-Based Systems Engineering (MBSE)

Keywords

Keywords

Dr Darren explains:
If you are new to SysML, don't be too concerned about whether your modelling is perfect first up, because the great thing about MBSE tools - especially SysML tools - is they invite incremental improvement, and your fixes flow through all diagrams, thanks to the power of Single Source Of Truth!

Modelling in SysML tools is part Science and part Art.

The Webel Recipe for SysML-friendly Wolfram Language coding in Mathematica

Keywords

Keywords

As part of a long term project developed, initially during work for a client, Webel IT Australia in partnership with GreenSoft Pty Ltd is developing a very complex Mathematica application with substantial SysML modelling support.

Screencast: Cameo Simulation Toolkit: v19SP3: Analysis: When a Property is typed by an abstract Block an instance of a concrete specialising Block will automatically be created and assigned even when the lower multiplicity is 0

Keywords

Video style

This screencast video is an analysis of this suspected issue:
Cameo Simulation Toolkit: v19SP3: GOTCHA/BUG: When a Property is typed by an abstract Block an instance of a concrete specialising Block (where available) will automatically be created and assigned even when the lower multiplicity is 0
It also includes a nice demo of using an Activity and Actions to simulate instance creation and assignment in Magic Model Analyst® (Cameo Simulatio

CATIA Magic zone

Keywords

Keywords

In 2018, Dassault Systèmes acquired No Magic Inc, the developers of the MagicDraw/Cameo family of software products for Unified Modeling Language (UML®) and Systems Modeling Language v1 (SysML®), which included including: MagicDraw® UML (aka Magic Software Architect), MagicDraw SysML Plugin, Magic Cyber-System

MEMKO Systems

MEMKO Systems has been appointed by Dassault Systèmes (who acquired No Magic in 2018) as the CATIA No Magic Value Solutions Partner and Reseller for Australia and New Zealand.

Screencast: SysML/MBSE: An air conditioner refrigerant cycle in Cameo Simulation Toolkit

Keywords

Video style

This video only shows the Activities and StateMachines. For the underlying Block model please visit this accompanying slide trail:
TRAIL: SysML: Simple model of an air conditioner with a refrigerant cycle and StateMachine driven by Activities in MagicDraw/Cameo
