This demonstrates one solution to the challenge identified here:
SysMLv1: Cameo Simulation Toolkit: HOW send to an intended recipient via a shared Port? ATTEMPT: Using multiple Connectors to every candidate recipient without a mediating hub [with mini video]
By using a mediating RoutingHub, the transmitter :TX does not have direct connections to the candidate rx1:RX and rx2:RX receivers. This avoids insecure sending of the Signal along multiple direct Connectors from the sending Port on :TX.
Click on the image to view it full size
Watch simulation
Watch a high resolution version of the video on Vimeo.

The implementation shown does not scale well because the forwarding logic for the receivers is too static. It could be scripted to make the forwarding logic more generic. It is possible using the Action Language Helper (ALH) API or Action Language for Foundational UML (ALF) to parametrise the dispatch by 'idTo'.
