Webel: SysML symbol colour styles: Recommend use black symbol borders and no symbol fill (or white symbol fill) EXCEPT for special highlighting. Recommend DO NOT use the default VENDOR-SPECIFIC line and fill colours for symbols! [TIP IS MOSTLY IGNORED]

Icon class
icon_class
far fa-sticky-note
icon_class_computed
far fa-sticky-note
Note kind
Policy level
Specification keywords
Keywords

This is a very strong recommendation from Dr Darren, even if this recommendation is usually completely ignored.

Have you somehow fallen in love with the default MagicDraw/Cameo SysML symbol colours (which are in fact completely arbitrary and are just the left-over ones that were not taken already for the old MagicDraw UML symbol colours)?

In our workshop courses, one of the first tips is to load a starting style file into the MagicDraw® UML or Magic Cyber-Systems Engineer ® (Cameo Systems Modeler®) tools that has no colours other than black and white!

HINT: Patent applications only accept line drawings in black and white! SysML is ideal for creating figures for patent applications!
Dr Darren says:
In the Webel SysML/MBSE course a typical b/w .stl starting point style file is provided, or you can adapt the OMG b/w style. And yes, since nearly everyone ignores this advice anyway, you can very easily switch between Webel's style set and the familiar (but completely arbitrary) MagicDraw/Cameo default coloured styles.

You can easily switch back to the default colour & style set in the tool if you have for some reason indeed fallen in love with the MagicDraw/Cameo SysML symbol colours, just use Project Options > Symbol Style.


BTW: I love colour, and I have nothing against colour per se, it's just not always optimal for SysML diagramming. I even do colourful light synthesis art (using a device I designed using SysML) and colourful flower photography.
